129kWh Electrical Cabinet Outdoor 108kW Energy Storage System
| MOQ: | 1 |
| Price: | 699-69999 USD per set |
| Standard Packaging: | Standard Packaging |
| Delivery Period: | Expected shipment within 30 days after successful payment |
| Payment Method: | D/P T/T |
| Supply Capacity: | 5000 units per year |
Detail Information
Place of Origin
Shenzhen, Guangdong, China
Brand Name
HUAHUI
Certification
UN38.3、UL、CE、KC、FCC、PSE、FDA and MSDS
Product Name:
Outdoor Electrical Cabinets
Type:
Outdoor Electrical Enclosures Cabinets
Feature:
Weatherproof, Dustproof
Protection Grade:
IP55/IP65
Installation Method:
Ground Installation
Advantage:
High Security
Highlight:
129kWh Electrical Cabinet Outdoor
,Electrical Cabinet Outdoor 108kW
,108kW Energy Storage System
Product Description
129kWh Electrical Cabinet Outdoor 108kW Energy Storage System
Our 129kWh-23 Outdoor Electrical Cabinet is an intelligent string energy storage system designed for reliable outdoor operation. We provide comprehensive outdoor cabinet solutions and custom products tailored to your specific requirements.
Product Overview
This fully enclosed, intelligent, and flexible outdoor cabinet series features an open frame "Lego brick" structure that enables easy spatial expansion and enhanced heat dissipation. The modular design allows customers to efficiently upgrade existing network equipment while maximizing site value. Equipped with an intelligent power system, it provides comprehensive management of site security, operational status, batteries, and more.
Key Advantages
- Smooth Evolution: Modular framework enables quick on-site cabinet combinations for continuous space expansion
- Safe & Reliable: IP55 sealed design with 60KA lightning protection for outdoor safety
- Green Energy Efficiency: Advanced heat exchange natural cooling reduces energy consumption
- Ultra-Quiet Operation: Fully enclosed design provides 10dBA lower noise than industry average
- One-Stop Installation: Pre-integrated components enable direct site installation
- Intelligent Management: Remote monitoring of environmental conditions and system status
System Specifications
| Parameter | Specification |
|---|---|
| Model Name | 215-2S12 |
| Rated Capacity | 215.0kWh |
| Maximum Charge/Discharge Rate | 0.5 CP |
| Maximum Cycle Efficiency | 91.3% |
| Dimensions (W×D×H) | 1150mm × 1800mm × 2100mm |
| Weight | ≤ 2.8 T |
| Operating Temperature | -30°C to 55°C (derating above 50°C) |
| Protection Level | IP55 |
| Noise Level | 65 dB(A) |
Battery Specifications (DC Side)
| Parameter | Specification |
|---|---|
| Battery Type | Lithium Iron Phosphate (LFP) |
| Rated Capacity | 280Ah |
| System Configuration | 240S1P |
| Number of Battery Packs | 4 |
| Voltage Range | 648-864 V |
PCS Specifications (AC Side)
| Parameter | Specification |
|---|---|
| PCS Model | PCS2000-108K-MB1 |
| Rated Power | 108 kW |
| AC Voltage/Frequency | 380/400/415 V (three-phase four wire), 50/60 Hz |
| Maximum Power Factor | -1 to +1 |
Performance Features
Intelligent Temperature Control: "Smart Cold Router" thermal management system provides adaptive multi-mode control, reducing energy consumption by 30%.
Extended Lifespan: Advanced heat dissipation design including high-low temperature zoning and dual-circuit cross flow cooling ensures reliable performance under demanding conditions.
Technical Highlights
- Easy Spatial Expansion: Modular framework supports continuous cabinet space expansion
- Upgradable Cooling: Replaceable door-mounted heat exchangers for enhanced heat dissipation
- Flexible Configuration: Compatible with 21/19-inch equipment and flexible wiring options
- Intelligent Management: Remote monitoring of environmental conditions, security, and battery health
- Multiple Power Options: Supports remote power, AC power, and diesel engine interfaces
- Space-Efficient Design: Front-opening design reduces maintenance area by 45%
- High Reliability: IP55 sealing and 60KA lightning protection ensure outdoor safety
Custom Solutions Available: We offer a comprehensive range of outdoor cabinet products and can develop tailored solutions to meet your specific requirements. Contact us via email or WhatsApp for detailed inquiries and professional assistance.
