Integrated Energy Storage Cabinet 10kWh-430kWh Photovoltaic Energy Storage
| MOQ: | 1 |
| Price: | 700-7000 USD per set |
| Standard Packaging: | Standard Packaging |
| Delivery Period: | Expected shipment within 30 days after successful payment |
| Payment Method: | D/P T/T |
| Supply Capacity: | 5000 units per year |
Integrated Energy Storage Cabinet 10kWh
,430kWh Photovoltaic Energy Storage
,10kWh Photovoltaic Energy Storage
10-430kWh Photovoltaic Energy Storage Cabinet integrated cabinet
Product Introduction
1. This is industrial and commercial energy storage system, which is a fully integrated pre configured solution suitable for scenarios such as photovoltaic energy, industry and commerce, power grids, power plants, charging stations, public services, etc.
2. Off grid microgrid systems are suitable for areas with unstable electricity, villas, farms, islands, oil extraction, and other areas without electricity. Main functions: self use, emergency backup power, oil engine management, wind turbine management, etc
3. This product is mainly suitable for industrial and commercial microgrid energy storage solutions, and is very efficient and reliable for small and medium-sized enterprises and businesses. If customers need to increase capacity, they can connect in parallel cabinets.
Product System Diagram
|
01 Cooling air duct |
06 Fire Protection System |
|
02 Air conditioning system |
07 EMS Display Screen |
|
03 Battery PACK |
08 EMS host |
|
04 High voltage BMS |
09 PCS |
|
05 High Voltage Box |
10 Distribution System |
Product parameters
Product selection and configuration table for air-cooled energy storage cabinets
|
PRODUCT MODEL |
HH-906868 |
HH-136868 |
HH-167676 |
HH-209595 |
HH-259595 |
HH-211111 |
HH-251919 |
HH-211711 |
|
Capable of installing battery capacity |
10-15kWh |
20-25kWh |
30-35kWh |
45kWh |
55kWh |
100kWh |
100kWh |
200kWh |
|
Battery installation configuration |
The interior space of the cabinet can be equipped with racks or non-standard, single 5-46.3kWh battery PACKs, and can be connected in series or parallel with multiple PACKs |
|||||||
|
External dimensions H * W * D |
900*680*680 |
1300*680*680 |
1600*760*760 |
2050*950*950 |
2500*950*950 |
2100*1050*1050 |
2500*1850*1150 |
2100*1650*1050 |
|
Internal dimensions H * W * D |
750*600*600 |
1100*600*600 |
1400*700*700 |
1800*800*800 |
2300*800*800 |
1950*940*940 |
2300*1700*1000 |
1950*1540*940 |
|
Cabinet material |
Steel plate/stainless steel/galvanized sheet |
|||||||
|
Open mode |
Front opening door/front and rear opening door |
|||||||
|
Heat dissipation method |
Air cooled air conditioner/air cooled fan (optional) |
|||||||
|
Fire Protection System |
Hot melt adhesive/heptafluoropropane/perfluorohexane (optional) |
|||||||
|
Power distribution unit |
AC input/output power distribution, DC input/output power distribution, electric meter, emergency stop switch indicator light (optional) |
|||||||
|
PCS |
3-5kW |
8-10 kW |
8-10 kW |
10-20 kW |
20-30 kW |
50 kW |
50 kW () |
100 kW |
|
Ambient Temperature |
-40°C to 75°C |
|||||||
|
Product temperature rise |
Can provide actual product temperature rise test report |
|||||||
|
protection grade |
IP20/IP55/IP66 |
|||||||
|
system certification |
IS09001,IS014001,IS045001 |
|||||||
|
Branding |
HUAHUI |
|||||||
Product selection and configuration table for liquid cooled energy storage cabinets
|
PRODUCT MODEL |
HH-221313-A |
HH-221313-B |
HH-229613 |
|
Capable of installing battery capacity |
325kWh |
232kWh |
232kWh |
|
Battery installation configuration |
The interior space of the cabinet can accommodate 5-7 46.3kWh liquid cooled battery packs |
||
|
External dimensions H * W * D |
2265*1330*1330 |
2265*1330*1330 |
2265*960*1330 |
|
Internal dimensions H * W * D |
2100*1240*1240 |
2100*1240*1240 |
2100*890*1240 |
|
Cabinet material |
Steel plate/stainless steel/galvanized sheet |
||
|
Open mode |
Front opening door/front and rear opening door |
||
|
Heat dissipation method |
Air cooled air conditioner/air cooled fan (optional) |
||
|
Fire Protection System |
Hot melt adhesive/heptafluoropropane/perfluorohexane (optional) |
||
|
Power distribution unit |
AC input/output power distribution, DC input/output power distribution, electric meter, emergency stop switch indicator light (optional) |
||
|
PCS |
100kW |
||
|
Ambient Temperature |
-40°C to 65°C |
||
|
Product temperature rise |
Can provide actual product temperature rise test report |
||
|
protection grade |
IP20/IP55/IP66 |
||
|
system certification |
IS09001,IS014001,IS045001 |
||
|
Branding |
Huahui |
||
Product parameters of 325kWh liquid cooled energy storage cabinet
|
PRODUCT MODEL |
HH-231313-01 |
|
Product size |
H*W*D 2300*1350*1350 |
|
Product Capacity |
325kwh |
|
Battery configuration |
7 46.4kWh liquid cooled PACKs |
|
Cabinet material |
Steel plate/stainless steel |
|
protection grade |
IP55/IP66 |
|
Heat dissipation method |
Liquid cooled air conditioner |
|
Fire Protection System |
Heptafluoropropane/Perfluorohexane (optional) |
|
Distribution parameters |
AC/DC (optional) |
|
PCS parameters |
100kW liquid cooling (optional) |
Product parameters of 232kWh liquid cooled energy storage cabinet
|
PRODUCT MODEL |
HH-221212-01 |
|
Product size |
H*W*D 2200*1220*1220 |
|
Product Capacity |
232kwh |
|
Battery configuration |
5 46.4kWh liquid cooled PACKs |
|
Cabinet material |
Steel plate/stainless steel |
|
protection grade |
IP55/IP66 |
|
Heat dissipation method |
Liquid cooled air conditioner |
|
Fire Protection System |
Heptafluoropropane/Perfluorohexane (optional) |
|
Distribution parameters |
AC/DC (optional) |
|
PCS parameters |
100kW liquid cooling (optional) |
Product parameters of 400-430kWh air-cooled energy storage cabinet
|
PRODUCT MODEL |
HH-223112-01 |
|
Product size |
400kWh,H*W*D 2200*3100*1200 430kWh,H*W*D 2350*3200*1000 |
|
Product Capacity |
400-430kWh |
|
Battery configuration |
28-30 pieces of 48V280AH |
|
Cabinet material |
Steel plate/stainless steel |
|
protection grade |
IP55/IP66 |
|
Heat dissipation method |
Intelligent air conditioning |
|
Fire Protection System |
Heptafluoropropane/Perfluorohexane (optional) |
|
Distribution parameters |
AC/DC (optional) |
|
PCS parameters |
200kw (optional) |
Product parameters of 200-215kWh air-cooled energy storage cabinet
|
PRODUCT MODEL |
HH-221511-01 |
|
Product size |
200kWh,H*W*D 2200*1500*1100 215kWh.H*W*D 2360*1660*1100 |
|
Product Capacity |
200-215kWh |
|
Battery configuration |
14-15 pieces of 48V280AH |
|
Cabinet material |
Steel plate/stainless steel |
|
protection grade |
IP55/IP66 |
|
Heat dissipation method |
Intelligent air conditioning |
|
Fire Protection System |
Heptafluoropropane/Perfluorohexane (optional) |
|
Distribution parameters |
AC/DC (optional) |
|
PCS parameters |
100kw (optional) |
Product parameters of 100kWh air-cooled energy storage cabinet
|
PRODUCT MODEL |
HH-221010-01 |
|
Product size |
H*W*D 2200*1000*1000 |
|
Product Capacity |
100kWh |
|
Battery configuration |
7 pieces of 48V280AH |
|
Cabinet material |
Steel plate/stainless steel |
|
protection grade |
IP55/IP66 |
|
Heat dissipation method |
Intelligent air conditioning |
|
Fire Protection System |
Heptafluoropropane/Perfluorohexane (optional) |
|
Distribution parameters |
AC/DC (optional) |
|
PCS parameters |
50kw (optional) |
Product parameters of 55kWh air-cooled energy storage cabinet
|
PRODUCT MODEL |
HH-259191-01 |
|
Product size |
H*W*D 2500*910*910 |
|
Product Capacity |
55kWh |
|
Battery configuration |
11 (4U) 48V100AH |
|
Cabinet material |
Steel plate/stainless steel |
|
protection grade |
IP55/IP66 |
|
Heat dissipation method |
Intelligent air conditioning |
|
Fire Protection System |
Heptafluoropropane/Perfluorohexane (optional) |
|
Distribution parameters |
AC/DC (optional) |
|
PCS parameters |
20-30kw (optional) |
Product parameters of 45kWh air-cooled energy storage cabinet
|
PRODUCT MODEL |
HH-219191-01 |
|
Product size |
H*W*D 2100*910*910 |
|
Product Capacity |
45kWh |
|
Battery configuration |
9 (4U) 48V100AH |
|
Cabinet material |
Steel plate/stainless steel |
|
protection grade |
IP55/IP66 |
|
Heat dissipation method |
Intelligent air conditioning |
|
Fire Protection System |
Hot melt adhesive/heptafluoropropane (optional) |
|
Distribution parameters |
AC/DC (optional) |
|
PCS parameters |
10-20kw (optional) |
Product parameters of 30-35kWh air-cooled energy storage cabinet
|
PRODUCT MODEL |
HH-167676-01 |
|
Product size |
H*W*D 1650*760*760 |
|
Product Capacity |
30-35kWh |
|
Battery configuration |
6-7 (4U) 48V100AH |
|
Cabinet material |
Steel plate/stainless steel |
|
protection grade |
IP55/IP66 |
|
Heat dissipation method |
Intelligent air conditioning |
|
Fire Protection System |
Hot melt adhesive/heptafluoropropane (optional) |
|
Distribution parameters |
AC/DC (optional) |
|
PCS parameters |
8-10kw (optional) |
Product parameters of 20-25kWh air-cooled energy storage cabinet
|
PRODUCT MODEL |
HH-136666-01 |
|
Product size |
H*W*D 1350*660*660 |
|
Product Capacity |
20-25kWh |
|
Battery configuration |
4-5 (4U) 48V100AH |
|
Cabinet material |
Steel plate/stainless steel |
|
protection grade |
IP55/IP66 |
|
Heat dissipation method |
Intelligent air cooling/intelligent air conditioning |
|
Fire Protection System |
Hot melt adhesive (optional) |
|
Distribution parameters |
AC/DC (optional) |
|
PCS parameters |
8-10kw (optional) |
Product parameters of 10kWh air-cooled energy storage cabinet
|
PRODUCT MODEL |
HH-136666-01 |
|
Product size |
H*W*D 1350*660*660 |
|
Product Capacity |
10-15kWh |
|
Battery configuration |
2-3 (4U) 48V100AH |
|
Cabinet material |
Steel plate/stainless steel |
|
protection grade |
IP55/IP66 |
|
Heat dissipation method |
Intelligent air cooling/intelligent air conditioning |
|
Fire Protection System |
Hot melt adhesive (optional) |
|
Distribution parameters |
AC/DC (optional) |
|
PCS parameters |
3-5kw (optional) |
Main features
1. Security
Software+hardware+electrical, multi-level protection.
Independent cabinets achieve electrical and fire safety isolation, preventing the spread of accidents.
Convert DC convergence to AC convergence to prevent DC arcing.
2. Efficient
Cluster by cluster management, eliminating parallel losses and improving energy storage revenue.
PCS three-level topology, with a maximum efficiency of 99%.
3. High integration
Integrated: battery+BMS+PCS+EMS+fire protection+temperature control.
4. Easy to use
Rapid deployment, decentralized deployment and centralized scheduling.
Distributed, easy to expand, supports parallel connection of multiple cabinets on the AC side.
Fully modular design, easy to maintain.
Cloud monitoring+mobile app support.
