IP55/IP65/IP66 Customizable Outdoor Electrical Cabinet 60kA, Hermetically Sealed
215kWh Energy Storage Cabinet
,IP55 Outdoor Energy Storage System
,60kA Lightning Protection Intelligent String Energy Storage
The T-Series outdoor energy storage cabinet is a fully enclosed, intelligent, and highly flexible solution featuring an open-frame "Lego brick" modular structure. This innovative design enables seamless spatial expansion and enhanced heat dissipation efficiency, allowing effortless upgrades to existing network equipment while maximizing site value. Perfect for renewable energy integration, critical backup power, or industrial applications, it balances durability, adaptability, and performance for outdoor deployment.
- Seamless Scalability: Modular framework supports on-site cabinet combinations for hassle-free spatial expansion as energy demands grow
- Superior Safety & Reliability: IP55-rated sealed enclosure with 60kA lightning protection ensures robust resistance against dust, water ingress, and electrical surges
- Eco-Friendly Energy Efficiency: Advanced heat exchange cooling technology minimizes energy consumption, reducing operational costs and carbon footprint
- Ultra-Quiet Operation: Fully enclosed structure provides exceptional sound insulation for noise-sensitive areas
- Turnkey Installation: Pre-integrated core components enable direct on-site setup, reducing installation time and labor costs
- Intelligent Remote Management: Real-time monitoring of environmental conditions and system status for proactive maintenance and remote control
| Model Name | 215-2S12 |
| Rated Capacity | 215.0 kWh |
| Maximum Charge/Discharge Rate | 0.5 Cp |
| Maximum Cycle Efficiency | 91.3% |
| Dimensions (W*D*H) | 1150mm * 1800mm * 2100mm |
| Weight | ≤ 2.8 T |
| Working Temperature Range | -30°C to 55°C |
| Protection Level | IP55 |
| Lightning Protection Level | Type II (AC port) |
| Noise Level | 65 dB(A) |
| Battery Type | Lithium Iron Phosphate (LFP) |
| Rated Capacity | 280 Ah |
| System Configuration | 240S1P |
| Number of Battery Packs | 4 |
| Battery Voltage Range | 648-864 V |
| PCS Model | PCS2000-108K-MB1 |
| Rated Power | 108 kW |
| AC Voltage & Frequency | 380/400/415 V, 50/60 Hz |
| Maximum Power Factor | -1 to +1 |
- Intelligent Temperature Control: Smart thermal management system with adaptive multi-mode switching reduces energy consumption by 30% while optimizing battery performance and extending service life
- Extended Service Life: Advanced heat dissipation design including high-low temperature zoning and dual-circuit cross-flow cooling ensures stable long-term operation amid extreme temperature fluctuations
- Modular cabinet combinations for effortless spatial expansion
- Upgradeable heat dissipation capacity to match evolving energy demands
- Flexible internal structure compatible with 21/19-inch standard equipment
- Comprehensive intelligent management with 24/7 remote monitoring
- Versatile power access options (remote supply & AC supply)
- Front-opening design reduces required maintenance area by 45%, enhancing operational convenience
We offer a comprehensive range of outdoor energy storage cabinet products and specialize in developing tailored solutions to align with your specific technical, spatial, and operational needs. For detailed inquiries, personalized recommendations, and professional support, please contact us via email or WhatsApp.
