Heavy-Duty All-Weather Outdoor Power Cabinet IP55 with Integrated Heat Exchanger and 60kA Surge Protection. Fully enclosed outdoor electrical cabinets designed for extreme environmental conditions with advanced heat exchange technology.
The D Series represents our classic fully enclosed heat exchanger outdoor cabinet solution, engineered to withstand extreme conditions including high temperatures, severe cold, desert climates, and offshore locations. These cabinets are ideal for rapid outdoor deployment of high-capacity copper cables and OLT equipment, with proven reliability recognized by operators worldwide and currently deployed in over 100 countries.
- Excellent EMC performance with IP55 protection rating
- Suitable for extreme conditions including high temperatures, severe cold, wind, rain, and thunderstorms
- Dual cooling units and dual fans for enhanced operational safety
- Sealed design effectively isolates harmful dust and corrosive gases
- Maximum 60KA lightning protection module with MDF side line security unit
Heat exchanger fan with automatic speed adjustment for low noise and power consumption. Meets installation requirements in residential areas with quiet operation.
- Built-in hinges for anti-pry and anti-theft protection
- Built-in cabinet mounting holes for enhanced theft resistance
- HW-2801 door lock for equipment compartment and HW-2801B for wiring compartment
- Supports external door locks, electronic locks, audible/visual alarms, and reinforced battery bars
- Separate compartments for equipment and MDF enabling decentralized maintenance
Integrated cabinet solution includes main equipment, power supply, MDF/ODF, and monitoring systems. Complete delivery eliminates need for secondary on-site integration with quick installation and deployment capabilities.
- Equipment bay supports front-maintenance access
- MDF in wiring bay supports front-wiring operations
- Optional portable interior lighting for night maintenance
- AC power maintenance socket option for on-site maintenance tools
Real-time monitoring and remote alarming capabilities for all critical cabinet parameters including environmental conditions (temperature, humidity, access control), power supply equipment, batteries, patch panels, lightning protection modules, and cabinet fans.
| Parameter | Specification |
|---|---|
| Cabinet Dimensions | 1750mm x 800mm x 1850mm (W x D x H) |
| Battery Capacity | Two sets of 150Ah batteries |
| Maximum Weight (without battery) | 550kg |
| Maximum Weight (with battery) | 950kg |
| Operating Environment | -45℃ to +45℃ |
| Noise Standards | ETS300753 CLASS 4.1E City Level |
| Heat Dissipation | Heat Exchanger |
| Maximum Cooling Capacity | 3000W |
| Configuration | User Capacity |
|---|---|
| 2 DC MA5600T | 1536 (POTS + ADSL2+) 1024 (POTS + VDSL2/ADSL2+) 1792 VDSL2/ADSL2+ 2048 POTS |
| 2 DC HABDs + 1 DC HABF | 1312 (POTS + ADSL2+) 1856 POTS + 384 ADSL2+ 2688 POTS |
