Small Outdoor Power Cabinet IP55 40KA Lightning Protection For Harsh Environments
| MOQ: | 1 |
| Price: | 699-69999 USD per set |
| Standard Packaging: | Standard Packaging |
| Delivery Period: | Expected shipment within 30 days after successful payment |
| Payment Method: | D/P T/T |
| Supply Capacity: | 5000 units per year |
Detail Information
Place of Origin
Shenzhen, Guangdong, China
Brand Name
HUAHUI
Certification
UN38.3、UL、CE、KC、FCC、PSE、FDA和MSDS
Product Name:
Outdoor Electrical Cabinets
Type:
Telecom Battery Cabinet
Protection Grade:
IP55/IP65
Installation Method:
Ground Installation
Feature:
High Security
Application:
4G/5G Communication Base Station
Highlight:
Small Outdoor Power Cabinet IP55
,Outdoor Power Cabinet IP55 40KA
,40KA Lightning outdoor electrical cabinets
Product Description
Fully Enclosed Small Outdoor Power Cabinet (S Series)
The S series cabinet is a small-capacity enclosed natural cooling cabinet designed for outdoor applications. Featuring a sealed enclosure, it utilizes natural cooling through heat convection and conduction principles, eliminating the need for fans or heat exchangers.
Available in two models (F01S50 and S200), these cabinets support wall or pole mounting and are engineered for harsh environments including deserts, extreme cold, and offshore locations. They accommodate both AC and remote power supply modes, facilitating rapid outdoor deployment for copper cables and OLT equipment.
Key Features
- Safe and reliable: IP55-rated sealed design protects against dust and corrosive gases with 40KA maximum lightning protection, reducing equipment damage and maintenance costs.
- Green energy saving: Advanced natural cooling technology reduces energy consumption while supporting future upgrades for higher density equipment.
- Ultra-quiet operation: Fully enclosed design provides excellent sound insulation, averaging 10dBA quieter than industry standards.
- One-stop installation: Ships fully equipped with host devices, power distribution, batteries, cooling modules, and accessories for immediate deployment.
- Intelligent management: Supports remote monitoring of environmental conditions, access control, and system status through smart accessories.
Product Parameters
| Parameter | Specification |
|---|---|
| Cabinet size without battery compartment | 750mm * 350mm * 850mm (W * D * H) |
| Cabinet size with battery compartment | 750mm * 350mm * 1120mm (W * D * H) |
| Cabinet size with battery compartment and forced cooling module | 750mm * 350mm * 1200mm (W * D * H) |
| Battery capacity | 1 set of 26Ah or 40Ah batteries |
| Maximum weight | 72kg (basic cabinet), 147kg (fully equipped with 40AH battery) |
| Operating environment | -33℃ to +40℃ (with 1120W/m² solar radiation) |
| Noise standards | ETS300753 CLASS 4.1E PROTECTED AREA LEVEL |
| Heat dissipation | Closed self-cooling |
| Maximum cooling capacity | Self-cooling: 45℃/380W or 50℃/300W Forced cooling: 55℃/420W or 50℃/550W |
We offer comprehensive outdoor cabinet solutions and can customize products to meet specific requirements. Contact us via email or WhatsApp for inquiries. Our team is committed to providing exceptional support for your projects.
